Philips N4422

General

Manufacturer: Philips
Model: N 4422 (N4506 but with built-in amplifier and loudspeakers).
Years of manufacture: 1978 - 1981
Type: Tape machine
Made in: Austria
Color: Grey/Black
Remote control: Yes with optional remote Stop/Start
Power consumption: approx. 35W
Dimensions: (WxHxD) 557 x 437 x 210mm.
Weight: 15 kg
Original price approx.: 1'450 DM

Connections

Number of outputs: 2
headphones
line-out
Number of inputs: 4
line-in
Microphone
Phono
Tuner

Technical data

Max. coil diameter: 18cm
Drive: 3 motors
Heads: 3
Tracks: 4
Tape speeds: 4,75cm/s 9,5cm/s 19cm/s
Slip:
Synchronous fluctuations: 0.2% (4.75cm/s) 0.07% (9.5cm/s) 0.05% (19cm/s).
Pitch fluctuations:
Overall frequency response: 35-11000Hz (4.75cm/s) 35-19000Hz (9.5cm/s) 35-25000Hz (19cm/s).
Signal-to-noise ratio:
Signal-to-noise ratio:
Distortion ratio:
Equalization:
Crosstalk attenuation:
Cancellation attenuation:
Premagnetization and cancellation frequency:
Built-in amplifier with 2 loudspeakers

Special Features

DNL noise reduction
Automatic end-of-band shutdown
Rear band control
Horizontal and vertical operation
Subsequent erasure of unwanted recordings during playback
Variable rewind speed
Input and output level controls
Peak display
Counter with memory stop function
Multiplay
Motors can be switched off for monitor operation
Tape end switch-off at end of tape and tape breakage
Electronically controlled drive
Two microphone inputs
Microphone sensitivity adjustable in two steps
