A-7300 - Four Track Two Channel

The TEAC A-7300 features a direct-drive capstan motor for amazingly accurate tape speed control and minimum wow and flutter.

Eddy current induction reel motors for high efficiency and accurate tape tensioning.

Built in mixer allows you to blend signals from 4 mics, or 4 lines, or 2 mic and 2 line inputs. For live recording no external mixer is needed.

Tape-source and tape only outputs for added versatility and convenience; especially useful for creation of special effects such as echo, cross echo and sound on sound.

Edit switch allows you to edit out unwanted sections of tape by deactivating the take up reel motor.

Separate cue and pause controls - these permit cueing to a precise musical passage in either wind mode or play mode.

Separate master input level control for all mic/line inputs

Track system: 4-track, 2-channel, stereo/monaural system

Heads: 1 x erase, 1 x record, 1 x playback

Motor: 2 x reel, 1 x capstan

Reel size: up to 10.5 inch reel

Tape speeds: 3 3⁄4 7 1⁄2 ips

Wow and flutter: 0.05% (7 1⁄2 ips)

Frequency response: 25Hz to 28kHz (7 1⁄2 ips)

Signal to Noise Ratio: 60dB

Total harmonic distortion: 0.8%

Input: 100mV (line), 0.25mV (mic)

Output: 0.775V (line)

Dimensions: 548 x 440 x 246mm

Weight: 28kg

Deze topmachine is vers geserviced (o.a. meer dan 100 elco’s vernieuwd !!), gereinigd en afgeregeld en weer in topstaat voor vele jaren.

Destijds in de jaren ‘70 al een serieus kostbare machine met een prijs van Fl. 4500,- Gulden

Prijsidee 1350,- inclusief 3 maanden garantie. Banden in overleg.

Vooraf te beluisteren

Alleen ophalen aub
