Kenmerken

Type
Versterker

Beschrijving

Een geweldige klasse A buizenversterker. Was ooit een genot om naar te luisteren, maar hij staat nu al jaren in de kast. Zonde, daarom bied ik hem te koop aan.

Als je hem wilt luisteren, moet je zelf een muziekspeler meenemen, en boxen met snoeren. Dat heb ik allemaal niet meer.

De specificaties in het Engels:

  • Tubes: KT88-98 × 4 (Output Tubes)
  • 6N8P × 4 (Drivers and Cathode followers)
  • 12AX7B × 2 (Voltage amplifiers)
  • Maximum Output:
  • 30W per channel (8Ω and Triode Mode)
  • 60W per channel (8Ω and Ultra linear Mode)
  • Output Jacks: Two channels with two groups gold plated jacks
  • Output Impedance: 4Ω and 8Ω
  • Input Jacks: Gold plated isolated RCA jacks, 4 groups (CD, DVD, Tape, and Tuner) on rear, and 1 group on front as the input of post-stage mode
  • Input Sensitivity:
  • 0.25V in integrated mode (CD, DVD, and Tuner)
  • 0.6V in pure post-stage mode (Front input connectors)
  • Distortion of Harmonic Wave: ≤1.5%
  • Frequency Response: 5Hz ~ 80KHz (-2dB
  • Signal-to-Noise Ratio: 90dB (A weight)
  • Supply Voltage: AC 115V, 60Hz
  • Power Consumption: 250W
  • Net Weight: 23kg
...
...
...
...
...
...
...
...
...
...
...
...
