Kenmerken

Type
Versterker
Handelsnaam fabrikant
Tsakiridis
Postadres fabrikant
.
E-mailadres fabrikant
.

Beschrijving

We are the official Tsakiridis distributor in Netherlands.

For more information, check out our Audio-Vault website.

Features

Inputs: 1 line input
Input/Output connectors: RCA gold plated
Speaker connectors: Ultimax
Power supply capacitors: United Chemicon 105oC
Signal capacitors: Non inductive polypropelene film capacitors
Power resistors: Carbon film 5% tolerance
Power transformer: Handmade 250W each unit
Output transformer: Handmade 8 layer windings
Driving stage tubes: 1x6SL7, 1x EL34 each unit
Power tubes: 1x300B each unit

Specifications

Output Power: 2x8W
Input impedance: 100 kOhm
Output impedance: 6 Ohm
Input sensitivity: 1V
Signal to Noise Ratio (SNR): 85db
Rise time: 4us @ 10kHz
Harmonic distortion: 2W @ 1kHz 0.40%
Frequency response: -3db 14Hz-50000Hz
Power supply energy: 80Joule each unit
Power consumption: 95W each unit
Weight: 4.5kgr each unit
Dimensions (WxDxH): (17x43x22)cm
...
...
...
...
...
...
...
...
...
...
...
...
