JVC TD-V531

• Manufacturer: JVC
• Model: TD-V 531 black
• Type: Cassette Tape Deck
• Years of manufacture: 1990 - 1992
• Made in: Japan
• Color: Black
• Remote control: via Compulink only
• Power consumption: 19 W
• Dimensions: 435 x 133 x 288 mm (WxHxD)
• Weight: 4,8 kg
• Original price: 749 DM

Connections

• Number of inputs: 3
• Line In CD Direct,

Line In JVC System Bus (Compu- Link)

• Number of outputs: 3
• Line Out,
• Adjustable headphone output, 6.3mm phone jack
• JVC System Bus (Compu- Link)

Technical Data

• Sound heads: 3
• Motors: 3
• Synchronous fluctuations: 0.14% (DIN), 0.06 WRMS,
• Tape types: Normal (IEC I), Chrome (IEC II), Metal (IEC IV).
• Frequency response:
• Metal band: 10 - 21,000 Hz (Metal) and 15-19,000 Hz at +/- 3 dB,
• Chrome: 10 - 19,000 Hz, and 15-17,000 Hz at +/- 3 dB,

• Distortion factor: K3; 0.5%, THD: 1.0% (Metal band)
• Channel separation: 40 dB
• Signal-to-noise ratio: 59dB,
• with Dolby C: 74 dB at 500 Hz, 79 dB at 10,000 Hz.
• with Dolby B: 64 dB at 1 kHz, 69 dB at 10,000 Hz.

• Auto-Reverse: no
• Title search: yes, next title
• Dolby: B,C, HX Pro
• MPX filter: yes
• Fader: no
• Pitch control: no
• CD Synchro Recording: yes, with Compulink
• CD Direct circuit: high level input for clean recording

Special Features

• Dual Capstan tape guide, closed loop for fine, clean synchronisation
• 3 - head deck with rear tape control (monitor circuit)
• PCOCC - head windings for low oxygen sound transmission
• DDRP- Technology (Dynamics Detection Recording Processor) : recording level is adjusted for optimal conditions

Bias control

• CD Direct circuit : high level input for clean recording
• Music search
• Timer- pre-equipment for selective recording, playback
