TE KOOP : BANG OLUFSEN BEOLAB 3 SPEAKERS

Dimensions Length 16,2 cm
Width 13,5 cm
Height 21,5 cm; 22,3 cm on table ring
Weight 2,55 kg
Cabinet finish Silver and black
Power consumption IEC65: 20 W
Typical: 7 W
Stand-by: 0,2 W
Maximum Sound Pressure Level 94 dB (stereo, pair)
Power amplifier, bass 125 W, Class D, ICEPower
Power amplifier, treble 125 W, Class D, ICEPower
Long-term maximum output power
per amplifier Bass: 220 W/4ohm
Treble: 120 W/8ohm
Effective Frequency range 50 – 20.000 Hz
Crossover frequency 3.300 Hz
Cabinet principle Double Balanced Passive Radiator
Net volume, bass 1.5 litres
Magnetically shielded Yes
Woofer 101,6 mm
Passive radiators 2 x 101,6 mm
Tweeter 19 mm
Directivity control treble ALT (Acoustic Lens Technology), licensed from Sausalito Works LLC
Bass equalization ABL (Adaptive Bass Linearization)
Input sensitivity (Power Link) 125 mV (88dB SPL)
Input sensitivity (line) 125 mV (88dB SPL) – Auto switch on
Switch off time (line) 3 min.
Protection Thermal protection

Connections:
Power Link 1 (use Semi-Balanced PL cable type MKIII, or fully mounted PL cable)
Mains 1 Switch Mode Power Supply; internal jumper for 220-240 V or 100 – 120 V
Phono (line-in) Via PL using Line-to-PL adaptor cable, 5m, black

Tevens kunt u bij ons terecht voor reparaties Bang & Olufsen en Loewe apparatuur. (officieël service partner)
