Kenmerken
Beschrijving
Specifications
Performance:
Frequency Response (-3 dB): 80 Hz - 20 kHz
Frequency Range (-10 dB): 60 Hz - 30 kHz
System Sensitivity (1 W @ 1 m): 88 dB
Maximum SPL (Average/Peak): 105 dB / 111 dB
Dispersion: 90 degrees conical [1, 2]
Drivers & Crossover:
Low Frequency: 150 mm (6.00") mineral loaded cone
High Frequency: 20 mm (0.79") soft dome
Crossover Frequency: 5.4 kHz (2nd order LF/HF) [1, 2, 3, 4, 5]
Power & Impedance:
Power Handling: 60 W (Average), 120 W (Programme), 240 W (Peak)
Nominal Impedance: 16 Ohms
Transformer Taps: 70V: 60/30/15/7.5W | 100V: 60/30/15W [1, 2]
Performance:
Frequency Response (-3 dB): 80 Hz - 20 kHz
Frequency Range (-10 dB): 60 Hz - 30 kHz
System Sensitivity (1 W @ 1 m): 88 dB
Maximum SPL (Average/Peak): 105 dB / 111 dB
Dispersion: 90 degrees conical [1, 2]
Drivers & Crossover:
Low Frequency: 150 mm (6.00") mineral loaded cone
High Frequency: 20 mm (0.79") soft dome
Crossover Frequency: 5.4 kHz (2nd order LF/HF) [1, 2, 3, 4, 5]
Power & Impedance:
Power Handling: 60 W (Average), 120 W (Programme), 240 W (Peak)
Nominal Impedance: 16 Ohms
Transformer Taps: 70V: 60/30/15/7.5W | 100V: 60/30/15W [1, 2]
...
...
...
...
...
...
...
...
...
...
...
...
