Dolby Lake Processor LP4D12 Audio Processor

Audio processor in perfecte staat!

Inclusief:
- Dante audio
- AES / EBU-interfacekabel
Sub-D 25-pin plug naar 4 XLR male en 4 XLR female
Sub-D-connector: Neutrik (Rean)

The Dolby Lake Processor will improve the sound of any system. Effortless control is provided throughout the Dolby Lake Controller software, or the exclusive front-panel portal metering and control interface.

The Processor platform offers complete, native‐digital signal processing functionality, with support for up to 4‐in, 12‐out loudspeaker applications and 8 in, 8‐out EQ applications. The signal processing can also be changed to provide an EQ 4×4 configuration together with a loudspeaker 2×6 configuration.

The Processor includes several advanced technologies for improving sound quality. These include Raised Cosine Equalization (the foundation underlying the Ideal Graphic EQ and Lake Mesa EQ interfaces), plus linear phase crossovers, LimiterMax loudspeaker protection, and Iso‐Float ground isolation.

Features

Conversion resolution: 24-bit
Internal sample rate: 96kHz
Internal data path: 32-bit floating point
System propagation delay: 2 milliseconds any input to any output
Operating sample rates: 44.1kHz, 48kHz, 88.1kHz, 96kHz
THD+noise: 0.00003% typical, 20Hz to 20kHz
Dynamic range: 140dB typical, 20Hz to 20kHz
