Productinformatie

• Uniview
• DVR 5n1
• Gemakkelijk bereik
• 16 BNC videokanalen (IP-vervangbaar )
• AHD, TVI, CVI, CVBS, CVBS
• Ondersteunde bandbreedte van 40 Mbps
• Maximale IP-resolutie 8 Mpx
• Maximale analoge resolutie 5 Mpx
• Audio
• HDMI- en VGA-uitgang
• 2 x USB 2.0
• Muis
• Ruimte voor 1 HDD tot 6 TB
• WEB-, CMS-, smartphone- en NVR-interface
• ONVIF-compatibel

BrandUniviewRangeEasyVideo formatHDTVI / HDCVI / AHD / CVBS / IPVideo inputs16CH BNCHybrid configurationUp to 16 IP Channels (8Mpx) replacing all the BNC channelsVideo outputs1 HDMI Full HD, 1 VGAAudio inputs1 Channel RCAAudio outputs1 Channel RCABidirectional audioReusing the audio input/outputDisplay resolution1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768Maximum IP recording resolution8 MpxAnalog cameras supportedTVI / AHD: 5MP@12FPS; 4MP@15FPS; 1080P@30FPS; 720@30FPS

CVI: 1080P@30FPS;720P@30FPS

*For the correct live display, the combination of resolution and FPS
of the connected analog cameras must be equal to or lower than the specifications indicated, but in no case higher than the specifications indicated.Main Stream recording encodingTVI/CVI/AHD 5MPLite@6FPS; 4MPLite@15fps; 720P@15FPSExtra Stream recording encodingD1@6FPS; D1@8FPS; D1@10FPSRecording methodManual, programmed, motion detectionInternal memory1 HDD SATA 3.5" of up to 6TB (not included)External interface2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet)Remote accessWeb Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)PowerDC 12V / 10WDimensions / Weight260mm ×240mm× 46mm / 1.1 kg
