Beschrijving

Mercedes Xentry Passthru Software!!!
Works with 2024 cars








Vediamo 4.02.02 Tactrix Openport 2.0 Edition

installation guide / procedure how to use Vediamo 4.02.02 with the J2534 Tactrix Openport 2.0 device.

1. Install Tactrix Openport 2.0 driver
2. Install Vediamo 4.02.02
3. Patch Vediamo 4.02.02
4. Open “regedit“:

ComputerHKEY_LOCAL_MACHINESOFTWAREMicrosoftWindowsCurrentVersionSetupPnpResourcesRegistryHKLMSOFTWAREPassThruSupport.04.04Tactrix Inc. - OpenPort 2.0J2534 ISO/CAN/VPW/PWM
Copy name: “Tactrix Inc. - OpenPort 2.0 J2534 ISO/CAN/VPW/PWM”
5. Open Vediamo installation path and edit file “slave.ini“:
C:Program Files (x86)VediamoCaesardriverslave.ini
Insert the new name at Part J and save as slave.ini!

6. Open Vediamo
Generate key with key-generator
7. Vediamo Server CAESAR click on “Update“
Check Part J (and activate pinmapping)

8. Close Vediamo
Plug in Tactrix Openport 2.0
Start Vediamo now you should see “Part J: 1”
Click on ”Update” at Vediamo Server CAESAR and screen must look like this
...
...
...
...
...
...
...
...
...
...
...
...
