Product Type Features
Assembly Type: Electrical Connector
Product Type: Connector
Connector System: Wire-to-Wire
Sealable: Yes
Connector & Contact Terminates To: Wire & Cable
Shell Size: 20
Shielded: No
Connector Style: Plug
Shell Type: Plastic
Accessory Color: Black
Prewired: No

Configuration Features
Number of Positions: 5
Number of Power Positions: 0
Number of Signal Positions: 5
Preloaded: Yes
Keying: A
Factory Installed Backshell: No

Electrical Characteristics
Operating Voltage(VAC): 60
Operating Voltage(VDC): 60

Body Features
Shell Material: PBT
Insulation Material: Polyamide 66 GF25
Environmental Protection Type: Elastomer Sealed
O-Ring Material: Silicone
Environmental Protection: IP67
Peripheral Seal Material: Silicone

Contact Features
Contact Current Rating (Max)(A): 4
Reverse Gender: Standard
Contact Type: Male Contact

Mechanical Attachment
Polarization Code: A
Mating Alignment Type: Keyed
Mating Alignment: With
Flange: Without
Mating Retention Type: Threaded Coupling

Dimensions
Wire Size(AWG): 18 – 24
Wire Size(mm²): .82 – .2

Usage Conditions
Operating Temperature Range(°C): -40 – 85, -40 – 85
Operating Temperature Range(°F): -104 – 185
IP Water Sealing Level: IP67
IP Dust Sealing Level: 6

Operation/Application
Circuit Application: Signal
Durability Rating(Cycles): 100
Packaging Features

Other
 Field Serviceable: Yes

Packaging Quantity: 1
