Te Koop:

Warrior Mechanised Combat Vehicle 1987-1994 - Osprey New Vanguard 10

KIJK OOK EENS BIJ MIJN ANDERE ADVERTENTIES!!

Van Wikipedia:

The FV510 Warrior tracked vehicle family is a series of British armoured vehicles, originally developed to replace FV430 series armoured vehicles. The Warrior started life as the MCV-80, "Mechanised Combat Vehicle for the 1980s". One of the requirements of the new vehicle was a top speed able to keep up with the projected new MBT, the MBT-80 – later cancelled and replaced by what became the Challenger 1 – which the FV432 armoured personnel carrier could not. The project was begun in 1972; GKN Defence won the production contract in 1984 and the Warrior was accepted for service with the British Army in November 1984. Production commenced in January 1986 at Telford, with the first vehicles completed in December that year. GKN Defence was purchased by BAE Systems, via Alvis plc.

The first production vehicle was handed over to the Army in May 1987 to 1st Battalion Grenadier Guards, and from 1988 to 1990 four more armoured infantry battalions in the British Army of the Rhine were converted to the new vehicle.[8] A total of 789 FV510 and variants were manufactured for the British Army and 254 of a modified version (Desert Warrior) were produced for the Kuwaiti Army.

The Warrior incorporates several design features in keeping with the UK's battlefield experience. In particular, there are no firing ports in the hull, in line with British thinking that the role of the armoured personnel carrier/infantry fighting vehicle (APC/IFV) is to carry troops under protection to the objective and then give firepower support when they have disembarked. The absence of firing ports also allows appliqué armour to be fitted to the sides of the vehicle, which is invariably applied to Warriors on operations. The cage armour used at one stage was replaced in 2007 by "Wrap Two" appliqué armour.[9][unreliable source?] The basic armour provides all-around protection against small arms ball ammunition.

The crew of a Warrior comprises the driver, seated in the front hull and the gunner and commander in the turret. The embarked infantry section can number up to seven soldiers, who are seated facing each other in the rear hull compartment. Passenger access is through an electric ram powered door at the rear of the hull, rather than a drop-down ramp as in the US M113 APC and M2 Bradley IFV. Warrior Section Vehicles are able to carry seven fully equipped soldiers together with supplies and weapons, including a number of anti-tank weapons, for a 48-hour battlefield day in nuclear/biological/chemical conditions.

The Warrior is driven by a Perkins-Rolls-Royce V8 Condor engine through a four-speed automatic gearbox. It is capable of a road speed of 46 miles per hour (74 km/h). The Warrior has the speed and performance to keep up with a Challenger 2 main battle tank over the most difficult terrain.
The vehicle is fitted with a two-man GKN Sankey turret, armed with a non-stabilised L21A1 30 mm RARDEN cannon capable of destroying some APCs at a maximum range of 1,500 m (1,600 yd), and an L94A1 EX-34 7.62 mm Hughes Helicopters coaxial chain gun. It is fitted with two clusters of four defensive grenade launchers (usually used with Visual and Infrared Screening Smoke – VIRSS).
All Warrior Infantry Section Vehicles are now equipped with Bowman radios, which replaced the earlier Clansman radios, for enhanced communications, command and control. When first introduced, the vehicles were fitted with passive image intensifier night vision sights. These have since been replaced with Thales Optronics Battle Group Thermal Imaging (BGTI) sights to upgrade night fighting capabilities, with 8× magnification.[7] As of 2007, 350 vehicles were fitted with BGTI.

Operation Granby (Gulf War)
Operation Grapple (United Nations duties in Bosnia with the UNPROFOR)
Operation Resolute (NATO IFOR (Implementation Force) Bosnia 1996)
Operation Telic (Iraq from 2003)
Operation Herrick (Afghanistan with ISAF)
The protection against small arms, missiles, rocket-propelled grenades and anti-tank mines was shown during the UN operations in Bosnia. Two Warriors were destroyed during the First Gulf War, with nine soldiers killed, in a friendly fire incident when hit by AGM-65 Maverick missiles launched in error by two American Fairchild Republic A-10 Thunderbolt II ground attack aircraft.[10]
As of 17 November 2008, 22 soldiers had been killed while travelling in Warrior IFVs in Afghanistan or Iraq.[11] On 7 March 2012, six British soldiers were killed in an explosion that hit a Warrior IFV in Helmand.

FV510 Infantry Section Vehicle. This is the principal version operated by the British Army, as described above. 489 were produced (including 105 as platforms for the mobility of anti-tank guided weapon teams, originally equipped with MILAN and later with Javelin missiles).[13]
FV511 Infantry Command Vehicle. 84 of these were produced.
FV512 Mechanised Combat Repair Vehicle. Operated by REME detachments in Armoured Infantry battalions. It is equipped with a 6.5-tonne crane plus power tools and is able to tow a trailer carrying two Warrior power packs or one Challenger power pack. A total of 105 of these were produced.

FV513 Mechanised Recovery Vehicle (Repair). Also operated by REME detachments in Armoured Infantry battalions. It is equipped with a 20-tonne winch and 6.5-tonne crane plus power tools and (like the FV512) is able to tow a trailer carrying two Warrior power packs or one Challenger power pack. 39 of these were produced.
FV514 Mechanised Artillery Observation Vehicle. This is operated by the Royal Artillery as an Artillery Observation Post Vehicle (OPV) and is fitted with mast-mounted Man-packable Surveillance and Target Acquisition Radar (MSTAR) and Position and Azimuth Determining System (PADS), with image intensifying and infra-red equipment. The only armament is the 7.62 mm machine gun, as the 30 mm RARDEN cannon is replaced by a dummy weapon. This allows space for the targeting and surveillance equipment while still keeping largely the same outward appearance of a standard Warrior in order to avoid becoming a priority target. 52 of these were produced.

FV515 Battery Command Vehicle. This is operated by the Royal Artillery. 19 of these were produced.
Desert Warrior. This was an export version adapted for operations in hostile desert conditions. It was fitted with the Delco turret as used on the LAV-25 wheeled IFV, mounting a stabilised 25 mm M242 Bushmaster chain gun with coaxial 7.62 mm chain gun and two Hughes TOW ATGM launchers (one mounted on each side). In 1993, Kuwait purchased 254 Desert Warrior vehicles.
Warrior 2000. This was a new version developed for the Swiss Army. It did not enter production. It featured an all-welded aluminium hull, increased armour, digital fire control system and more powerful engine. It was fitted with the Delco turret, or a Land Systems Hagglunds E30 turret with Alliant Techsystems 30 mm Bushmaster II Mk 44 cannon.
Armoured Ambulance. Six Warriors, with armaments removed, were converted to armoured ambulances for use in Afghanistan during Operation Herrick.[14]
VERDI-2 (Vehicle Electronics Research Defence Initiative) was a technology demonstrator built on the hull of an FV510 in 1993. It utilized the 40mm CTAI cannon[citation needed], in addition to eight Starstreak missiles in two quad launchers, as well as the ADAD system later seen on the Stormer HVM. It did not enter production.[15]
Optionally-Crewed Warrior. In late 2018, an optionally-crewed variant of the vehicle was demonstrated as part of the British Army's Army Warfighting Experiment 2018 'Autonomous Warrior'. This was delivered by British Engineering firm Digital Concepts Engineering.[16][17] The system was capable of remote operation over distance using a wireless mesh network over radio. Funding to explore the concept further was announced by Secretary of State for Defence Gavin Williamson in March 2019[18] but appears to have been de-prioritised since
