Audio interface AD DA voor soundkaart of unit

Audio interface AD DA printplaat voor soundkaart of unit

O.b.v. Cirrus Logic CS 42448-DQZ 423007

108 dB, 192 kHz 6-in, 8-out Multi-channel Codec

Kost bij AliExpress nu 52 euro, dus doe een leuk bod

Ophalen in Almere

Features
Six 24-bit A/D converters and eight 24-bit D/A converters
System sampling rates up to 192 kHz
A/D converter dynamic range
105 dB differential
102 dB single-ended
D/A converter dynamic range
108 dB differential
105 dB single-ended
THD+N (A/D and D/A converters)
-98 dB differential
-95 dB single-ended
A/D input mux – single-ended mode
Cirrus Logic Popguard® technology to minimize clicks and pops
Programmable A/D converter high-pass filter for DC offset calibration
Support for logic levels between 1.8 V and 5 V
Package: 64-pin LQFP; lead-free assembly
Selectable audio interface formats
Left-justified, I²S, TDM
Consumer and automotive D-grade availability
