Motu 828 mk2 externe geluidskaart met totaal 20 inputs en 22 outputs.
Werk ook goed standalone voor uitbreiding van je bestaande geluidskaart
voor 8 extra analoge in en uitgangen via ADAT !

- Total 20 inputs and 22 outputs
- Support 44.1kHz, 48kHz, 88.2kHz, 96kHz via ADAT (S/MUX)
- FireWire connectivity
- MIDI I/O
- CueMix DSP - for DSP-driven monitoring
- Stand-alone operation - Program your mixes in your studio then bring
your 828mkII to your gig without the need of your computer!
- Front panel Mic & Guitar inputs
- 8 TRS analog I/O
- ADAT lightpipe I/O
- S/PDIF I/O
- Sync includes Word Clock, ADAT Sync in and SMPTE I/O

The Ins & Outs:
The 828mkII provides the following simultaneous, independent inputs and outputs: 8
channels of quarter-inch TRS 24-bit 96kHz analog I/O (with individually switchable +4/-10
reference levels on input), 2 mic inputs with preamps and phantom power, 8 channels of 24-
bit ADAT optical digital I/O (4 channels at 96kHz), 24-bit 96kHz SPDIF digital I/O, headphone
out and stereo main out. All inputs and outputs can be individually addressed from host
audio software running on the computer. All inputs can also be individually addressed in the
828mkII's built-in CueMix DSP mixer. The headphone output and main outs each have
independent front-panel volume control. The headphone output can be programmed via
software to either mirror another pair of outputs (such as the main outs) or serve as its own
independent output pair.

Front Panel Access:
Two front-panel Neutrik combo (XLR/TRS) jacks with preamps and phantom power allow
you to connect a microphone, guitar or any quarter-inch input with front-panel convenience.
The XLR jack serves as a low-impedance mic input, and the TRS jack serves as a high-
impedance guitar/instrument input. Before A/D conversion, the pre-amplified signal from
each front-panel input is routed to one of two rear-panel quarter-inch analog sends, so that
you can insert a favorite outboard EQ, compressor, amp or effects processor to the mic/
guitar input signal before it is converted to digital form. The resulting output from the
outboard gear is fed back into the 828mkII via one of the eight TRS analog inputs on the rear
panel, for routing to the computer and/or inclusion in the 828mkII's built-in monitor mixes.

Built-in CueMix DSP Monitor Mixing:
The 828mkII provides DSP-driven digital mixing and monitoring for all 20 inputs. You can
connect mics, guitars, synths and effects processors, and monitor everything from the
828mkII's main outs or headphone jack with no separate mixer needed and no latency. The
828mkII supports up to four separate stereo monitor mixes assigned to any four digital or
analog output pairs. For example, separate monitor mixes could be set up for the main outs
and headphone outs, while two additional stereo buses could be used for send/return loops
to reverb units or other outboard gear. Each mix can support all 20 inputs (8 TRS analog, 2
mic, 8 ADAT optical digital and stereo SPDIF digital). A new "CueMix Bounce Back" feature
lets you route one of the four CueMix DSP mixes back to the computer. This allows you to
record your entire mix, including monitored inputs, back into the computer!

Front Panel Programming:
You can access your mixes, or any 828mkII setting, directly from the front panel using six
rotary encoders and a 2x16 backlit LCD display. Mix settings such as input gain, panning,
+4/-10 input level, 6dB boost, stereo pair grouping, mix output assignment and others are
quickly accessed, clearly marked and easy to adjust. You can create, save, recall and
duplicate eight global presets.

Graag alleen serieuze reacties
