Gigabyte Moederbord GA-7VRXP rev 2.0 Socket A (Dual BIOS)

Gigabyte Moederbord GA-7VRXP rev 2.0 (Dual BIOS).
Compleet in orginele doos, boekje en kabels. CD moet ik ook ergens hebben liggen. Moederbord is niet getest op werking, omdat ik er geen processor voor heb liggen.

• Socket A for AMD Athlon ™XP / AMD Athlon ™/ Duron ™processor
• Supports DDR333/DDR266 memory
• 8 USB ports (4 USB2.0) for widely expansion
• Promise advanced ATA 133 RAID 0,1 support
• Integrated Ethernet 10/100Mb Network Connection
• High Quality Creative Sound and via Line-out to support 5.1-channels
• Round corner PCB plate design for better solidness, better appearance

GIGABYTE patented Dual BIOS technology
Rich in overclocking features

GA-7VRXP (rev. 2.x)

• CPU: Socket A for AMD Athlon ™XP / Athlon ™/ Duron ™processor
• Chipset Southbridge : VIA 8233A(CE:
• VIA V-Link architecture (266MB/s)
• VIA VT6202 USB 2.0 controller
• Super I/O : ITE IT8705F
• Smart I/O : Winbond Smart@IO
• Promise PDC20276 ATA 133 RAID controller
• Raeltek 8100BL Ethernet 10/100Mb LAN controller
• Creative CT5880 PCI sound controller
• Sigmatel AC97 Codec chip
• Dual BIOS

Memory

• Type : DDR333 (PC2700) / DDR266 (PC2100) / DDR200 (PC1600) -184pin
• Max capacity : Up to 3GB by 3 DIMM slots(DDR266/200)

Expansion Slots

• 1 x AGP universal slot (4X/2X-AGP 2.0 compliant)
• 5 x PCI slots (PCI 2.2 compliant)

Back Panel Connectors

• PS/2 Keyboard / Mouse
• 2 x USB 1.1 ports
• 2 x COM ports
• 1 x RJ45 LAN port
• Audio (1 x Line-in / 1 x Line-out / 1 x Mic) connector
• 1 x joystick
• 1 x LPT

I/O Controller

• 1 x FDD port
• 4 x UDMA ATA133/100/66 Bus Master IDE ports
• 1 x 2ports USB 1.1 connector (by cable with rear USB bracket)
• 2 x 2ports USB 2.0 connector (by cable with rear USB bracket)

Memory Stick / Security Digital / Smart Card Reader connectors

• 2 x cooling fan pin header

H/W Monitoring

• System health status auto-detect and report by BIOS
• H/W detect & report power-in voltage, CPU voltage, and Fan Speed

BIOS

• Dual AMI BIOS, 2 x 2M bit flash ROM
• AMI BIOS with enhanced ACPI feature for PC98/Win98/Win2000/WinMe/XP compliance, Green, PnP, DMI, INT13 (>8.4GB) and Anti-Virus functions
• IDE#1~#4, SCSI, LS120, ZIP and CD-ROM bootable
• AC recovery ON/OFF control

Form Factor

• ATX
• Dimension : ( 23.5 x 30.4 cm )

Driver

• VIA 4 in 1 service pack utility
• Promise RAID controller driver ( includes pure ATA133 driver )
• Realtek LAN driver
• Creative sound driver
• VIA USB 2.0 driver
• Winbond Smart IO driver
• Free software

Other Features

• Suspend-To-RAM (STR)
• Supports USB KB/MS Wake up from S3
• Poly fuse for keyboard over-current protection

Power

• ATX power connector
• Power-off by Windows 95/98/Me/2000/NT/XP shut down and Switch
