• Support for Socket FM1 100W processors
• Supports Dual Channel DDR3 2400+(OC)
• Supports AMD Quad CrossFireX™, CrossFireX™ and Dual Graphics
• Graphics Output Options : D-Sub, DVI-D and HDMI
• Supports AMD Steady Video™ : New video post processing
• capability for automatic jitter reduction on home/online video
• 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
• Supports ASRock XFast RAM, XFast USB Technologies
• Supports Graphical UEFI, On/Off Play, Instant Boot, Instant
• Flash, APP Charger

Including:
· 16Gb RAM (4x 4Gb DDR3 1600 DIMM modules)
· AMD Athlon II X4 CPU (Liano 100 Watt , 3000MHZ, 1MBx4 Cache))

Specificaties:
CPU
- Support for Socket FM1 100W processors
- V4 + 1 Power Phase Design
- Supports AMD's Cool 'n' Quiet Technology
- UMI-Link GEN2
Chipset
- AMD A75 FCH (Hudson-D3)
Memory
- Dual Channel DDR3 memory technology
- 4 x DDR3 DIMM slots
- Supports DDR3 2400+(OC)/1866/1600/1333/1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*

• Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.

BIOS
- 32Mb AMI UEFI Legal BIOS with GUI support
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- DRAM, VDDP, VDDR, SB Voltage Multi-adjustment
Graphics
- Integrated AMD Radeon HD 65XX/64XX graphics in Llano APU
- DirectX 11, Pixel Shader 5.0
- Max. shared memory 512MB
- Three graphics output options: D-Sub, DVI-D and HDMI
- Supports HDMI Technology with max. resolution up to 1920x1200 @ 60Hz
- Supports Dual-link DVI with max. resolution up to 2560x1600 @ 75Hz
- Supports D-Sub with max. resolution up to 1920x1600 @ 60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required)
- Supports Blu-ray Stereoscopic 3D with HDMI
- Supports AMD Steady Video™: New video post processing capability for automatic jitter reduction on home/online video
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI and HDMI ports

• Some of AMD FM1 CPU (i.e AMD Athlon/Sempron family FM1 CPU) does not have integrated graphics processor. When this kind of CPU is installed, a discrete VGA card is required.

Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
LAN
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE
Slots
- 2 x PCI Express 2.0 x16 slots (PCIE2 @ x16 mode; PCIE4 @ x4 mode)
- 2 x PCI Express 2.0 x1 slots
- 3 x PCI slots
- Supports AMD Quad CrossFireX™, CrossFireX™ and Dual Graphics
