Seeed Studio LoRaWAN Gateway Module WM1302-SPI- EU868 Mhz

Omschrijving
WM1302 module is a new generation Long Range gateway module with mini-PCIe form-factor. Based on the SX1302 baseband Wio chip, WM1302 unlocks the greater potential capacity of long-range wireless transmission for gateway products. It features higher sensitivity, less power consumption, and lower operating temperature than the previous SX1301 and SX1308 Wio chip.

Powered by SX1302 baseband Wio chip, extremely low power consumption and high performance.
Mini-PCIe form factor with the standard 52-pin golden connector, easy to integrate with various gateway devices.
Ultra-low operating temperature, no additional heat dissipation needed, reducing the size of Long Range gateway.
High sensitivity down to -139 dBm @SF12 with SX1250 TX/RX front-end; TX power up to 26 dBm @3.3V.
Certified with CE, FCC, and TELEC. Simplify the final product certification process.
Frequency 863-870MHz
Sensitivity -125dBm @125K/SF7
-139dBm @125K/SF12
TX Power 26 dBm (with 3.3V power supply)
LEDs Power: Green Config: Red TX: Green RX: Blue
Form Factor Mini PCIe, 52pin Golden Finger
Power Consumption (SPI version) Standby: 7.5 mA
TX maximum power: 415 mA
RX: 40 mA
Power Consumption (USB version) Standby: 20 mA
TX maximum power: 425 mA
RX: 53 mA
LBT(Listen Before Talk) Support
Antenna Connector U.FL
Operating Temperature -40°C to 85°C
Dimensions 30 mm (width) × 50.95 mm (length)
Certification CE
