Broadcom BCM957504-N425G 25Gb/s Ethernet PCI Express4.0x16 SFF Network Adapter NEW

Type Network Adapter

Number of Ports 4 Ports

Model BCM957504-N425G

Compatible Port PCI Express4.0x16

General Description

The Broadcom® BCM957504-N425G is a quad-port 25 Gb/s PCI Express 4.0 x16 network adapter designed to the Open Compute Project (OCP) 3.0 Design Specification
in small form factor with four SFP28 network connectors.
The adapter supports SFP28/SFP+ optical modules and copper direct-attach cables. The network adapter uses the Broadcom BCM57504 100GbE MAC controller with an
integrated quad-channel 25GbE SFI transceiver

Features

n Quad-port pluggable media interface, compatible with a
SFP28/SFP+ optical transceiver or a copper directattach cable.
n Industry’s most secure PCIe adapter solution
leveraging Broadcom’s BroadSAFE® technology.
n Multi-Host up to four hosts.
n Fully compliant with the SFF-8402 standard.
n x16 PCI Express 4.0 compliant.
n SR-IOV with up to 1K virtual functions (VFs).
n Function-Level Reset (FLR) support.
n TruFlow™ flow processing engine.
n VXLAN, NVGRE, Geneve, GRE encap/decap.
n vSwitch Acceleration.
n Tunnel-aware stateless offloads.
n DCB support – PFC, ETS, QCN, DCBx.
n RDMA over Converged Ethernet (RoCE)
n Network Controller Sideband Interface (NC-SI).
n SMBus 2.0.
n MCTP over SMBus.
n Jumbo frames up to 9 KB.
n Advanced congestion avoidance.
n Multiqueue, NetQueue, and VMQ.
n IPv4 and IPv6 offloads.
n TCP, UDP, and IP checksum offloads.
n Large send offload (LSO).
n Large receive offload (LRO).
n TCP segmentation offload (TSO)
n Receive-side scaling (RSS).
n Transmit-side scaling (TSS).
n VLAN insertion/removal.
n Interrupt coalescing.
n Network boot – PXE, UEFI.
n iSCSI boot.
n Wake-on-LAN (WOL).
n MSI and MSI-X.
n OCP 3.0 FRU support.
n Conforms to the OCP 3.0 Design Specification Version 1.00.

Applications:

Quad-Port 25-Gigabit SFP28 Ethernet adapter for OCP systems

EAN: 8592978326197
SKU: BCM957504-N425G
UPC: 650861000482

Genoemde prijs is INCLUSIEF BTW

Artikelnummer 109099 op onze site QueenSystems
