Interface
WAN Port 1x 10/100/1000Base-TX, RJ-45 or 100/1000M Fiber SFP (FVac model)
LAN Port 4x 10/100/1000Base-TX, RJ-45
USB Port 2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer
Wi-Fi Antenna 2x External Dipole
Gain: 4 dBi for 5GHz, 2 dBi for 2.4GHz
(wireless model)
2.4G WLAN 802.11n 2x2 MIMO 300Mbps (n/ac/Vac model)
5G WLAN 802.11ac 2x2 MIMO 867Mbps (ac/Vac model)
FXS RJ-11 2 (Vac model)
Performance
NAT Throughput 500 Mbps
NAT Throughput w/ Hardware Acceleration 900 Mbps
IPsec VPN Performance 70 Mbps (AES 256 bits)
SSL VPN Performance 40 Mbps
Max. Number of NAT Sessions 30,000
Max. Concurrent VPN Tunnels 2
Internet Connection
IPv4 PPPoE, DHCP, Static IP, PPTP/L2TP
IPv6 PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel
Multi-VLAN/PVC
WAN Failover
Connection Detection ARP, Ping
WAN Data Budget
Dynamic DNS
DrayDDNS
LAN Management
VLAN 802.1q Tag-based, Port-based
Max. Number of VLAN 8
Number of LAN Subnet 4
DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
Wired 802.1x Authentication
Port Mirroring
Local DNS Server
Conditional DNS Forwarding
Hotspot Web Portal
Hotspot Authentication Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server
Networking
Routing IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2
Policy-based Routing Protocol, IP Address, Port, Domain
DNS Security (DNSSEC)
IGMP IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave
SMB File Sharing (Requires external storage)
VPN
LAN-to-LAN
Teleworker-to-LAN
Protocols PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IKEv2-EAP, IPsec XAuth, OpenVPN(Host to LAN)
User Authentication Local, RADIUS, mOTP
IKE Authentication Pre-Shared Key, X.509
IPsec Authentication SHA-1, SHA-256, MD5
Encryption MPPE, DES, 3DES, AES128, AES192, AES256
Single-Armed VPN
NAT-Traversal (NAT-T)
DrayTek VPN Matcher
Firewall & Content Filtering
NAT Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
VPN Pass-Through PPTP, L2TP, IPsec
IP-based Firewall Policy
Content Filtering Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
DoS Attack Defense
Spoofing Defense
Bandwidth Management
IP-based Bandwidth Limit
IP-based Session Limit
QoS (Quality of Service) TOS, DSCP, 802.1p, IP Address, Port, Application
VoIP Prioritization
Wireless LAN (wireless model)
Number of SSID 4 per radio band
Security Mode WEP, WPA, WPA2, Mixed(WPA+WPA2)
Authentication Pre-Shared Key, 802.1X
WPS PIN, PBC
WDS Bridge, Repeater
Access Control Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
AirTime Fairness
Band Steering (dual-band model)
WMM
VoIP Gateway (V model)
Protocol SIP, RTP/RTCP, ZRTP
SIP Registrars 12
Dial Plan Phone Book, Digit Map, Call Barring, Regional
Call Features Call Waiting, Call Transfer, Scheduled DND, Hotline
Voice Codec G.711 A/u law, G.726, G.729 A/B
Caller ID FSK_ETSI, FSK_BELLCORE, DTMF
Management
Local Service HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069
Config File Export & Import
Config File Compatibility Vigor2132 Series
Firmware Upgrade TFTP, HTTP, TR-069
2-Level Administration Privilege
Access Control Access List, Brute Force Protection
Notification Alert SMS, E-mail
SNMP v1, v2c, v3
Syslog
Managed by VigorACS
Central AP Management 2 VigorAP
Physical
Power Supply DC 12V @ 2A
Max. Power Consumption 19.2 watts
Dimension 207mm x 131mm x 42mm
Weight 410g
Operating Temperature 0 to 45°C
Storage Temperature -25 to 70°C
Operating Humidity (non-condensing) 10 to 90%
Certificate
