Raritan remote managed Rack PDU PX3-5493V

2 stuks beschikbaar. Prijs is per stuk.

Features
Branch Current Monitoring
Energy Metering
Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor
Metering Accuracy
ISO/IEC 62053-21 1%
Remote Outlet Switching
Yes
Metering per input line
Yes
Metering per Branch Circuit Breaker
Yes
Environmental Sensor Ready
Yes
Compatible Sensors
Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.
View all sensors.
PDU Linking
Link up to 8 PDUs where the Primary PDU has knowledge and power information from the attached Expansion PDUs. Redundant power from the first expansion unit ensures uptime even if the Primary PDU loses power.
Cascading
Physically cascade 32 PDUs under one ethernet port or 16 PDUs with USB using bridging mode, or additionally, save IP addresses using a single IP address with port forwarding.
Networking
(10/100/1000 Base T) Ethernet, Secondary redundant (10/100/1000 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).
Onboard Display
Color, matrix LCD display : Voltage, current, or active power (per line, per breaker, or per receptacle / outlet); Alarms; Configuration information (name, ratings, IP / Networking information). Auto-flip orientation
Specifications
Input

Input Plug
IEC 230V/32A 2P+PE 6Hr
Nominal Voltage
230V
Maximum Input Current
32A
Rated Input Current
32A
Power Capacity
7.4kVA
Cord Length
3m
Output

Nominal Voltage
240V
Receptacles (Output Connections)
(20) C13, (4) C19
Overload Protection
N/A
Physical

Dimensions (WxDxH)
52mm x 65mm x 1539mm
Unit Weight
11 lbs
Shipping Weight
16.975574 lbs
Shipping Dimensions
1819 x 230 x 118 mm
Mounting
G2-RACK-FOR-ZU
Environmental

Operating Temperature/Environment
60 C
Operating Relative Humidity
85%
Operating Elevation
0-6000ft
Conformance

Regulatory Approvals
CE
