Kenmerken
Conditie
Zo goed als nieuw
Type
Compressor
Beschrijving
IN ZEER NETTE STAAT
Specifications
Input Connectors
1/4" TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot HI
Input Impedance
>50kΩ balanced, >25kΩ unbalanced
Max Input
+24dBu, Balanced or Unbalanced
CMRR
>40dB at 1kHz, typically >55dB
Sidechain
1/4" TRS Phone, Normalled: Ring = Output (send); tip = Input (return)
Sidechain Impedance
Tip = >10kΩ (Input), Ring = 2kΩ (Output)
Sidechain Max Input Level
+24dBu
Output Connectors
1/4" TRS phone and XLR floating balanced, XLR: Pin 2 and Tip Hi
Output Impedance
120Ω balanced, 60Ω unbalanced
Max Output
+21dBu,>+20 dBm into 600Ω, balanced or unbalanced
Frequency Response
20Hz - 20kHz; +0, -0.5dB, Typical 3dB points are 0.35Hz and 110kHz, unity gain
Noise
<-90dBu, 22Hz to 22kHz, no weighting, unity gain
THD+Noise
Typically 60dB
Expander/Gate Attack Time
115 dB
Stereo Coupling
True RMS Power Summing™
Power Consumption
15 Watts Maximum
Operating Temperature
0°C to 45°C (32°F to 113°F)
Dimensions
1.75" x 19" x 6.75" (4.45 cm x 48.2 cm x 17.15 cm)
Unit Weight
5.05 lb (2.29 kg)
Shipping Weight
7.20 lb (3.27 kg)
Reference
0dBu = 0.775Vrms
Specifications
Input Connectors
1/4" TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot HI
Input Impedance
>50kΩ balanced, >25kΩ unbalanced
Max Input
+24dBu, Balanced or Unbalanced
CMRR
>40dB at 1kHz, typically >55dB
Sidechain
1/4" TRS Phone, Normalled: Ring = Output (send); tip = Input (return)
Sidechain Impedance
Tip = >10kΩ (Input), Ring = 2kΩ (Output)
Sidechain Max Input Level
+24dBu
Output Connectors
1/4" TRS phone and XLR floating balanced, XLR: Pin 2 and Tip Hi
Output Impedance
120Ω balanced, 60Ω unbalanced
Max Output
+21dBu,>+20 dBm into 600Ω, balanced or unbalanced
Frequency Response
20Hz - 20kHz; +0, -0.5dB, Typical 3dB points are 0.35Hz and 110kHz, unity gain
Noise
<-90dBu, 22Hz to 22kHz, no weighting, unity gain
THD+Noise
Typically 60dB
Expander/Gate Attack Time
115 dB
Stereo Coupling
True RMS Power Summing™
Power Consumption
15 Watts Maximum
Operating Temperature
0°C to 45°C (32°F to 113°F)
Dimensions
1.75" x 19" x 6.75" (4.45 cm x 48.2 cm x 17.15 cm)
Unit Weight
5.05 lb (2.29 kg)
Shipping Weight
7.20 lb (3.27 kg)
Reference
0dBu = 0.775Vrms
...
...
...
...
...
...
...
...
...
...
...
...
