WORK AREA

Table length: 800 / 950 / 1150 / 1250mm

Table width: 410 / 470 / 470 / 570mm

Table width in front of the disc: 250 / 300 / 300 / 400mm

Table under centre of the disc: 50mm

Table tilt motion down/up: 45/30°

Tilt motion with fine adjustment:

Reading accuracy: 6min

Zero lock:

Table swivel out: 90°

Table working height: 900mm

GRINDING DISC

Disc diameter: 500 / 600 / 800 / 900mm

Disc replacement:

MOTOR

Voltage: 400V

Motor power: 4.0 / 2.2 / 4.0 / 4.0kW

Revolutions per minute 1.500 / 1.000 / 750 / 750 U/min

Automatic brake (brake force regulator):

EXHAUST SYSTEM

Socket Ø bottom,top: 100mm, 120mm

Capacity: 814m³/h

Flow rate: 20m/s

SWITCHING UNIT

Main switch:

Emergency stop:

Switch for rotation to right / left:

DIMENSIONS

Space requirement S 550-EX / S 650-EX: 95x85x140 / 110x85x140cm

Space requirement S 850-EX / S 950-EX: 130x90x180 / 140x100x180cm

WEIGHT

S-version: 280 / 315 / 390 / 410kg
