JVC KD V11 Stereo Cassette Deck

Serviced!

• Type: Stereo Cassette Deck
• Tracks: 4-track / 2-channel stereo
• Tape Speed: 4.8 cm/sec
• Heads: 2 heads (1 for erase, 1 for record/playback, Metaperm material)
• Motor: Electronically controlled DC motor
• Tape Types Supported: Type I (Normal), Type II (CrO₂), Type IV (Metal)
• Noise Reduction: ANRS (Automatic Noise Reduction System) / Dolby B
• Frequency Response:
• Normal: ~30 Hz – 15 kHz
• Metal: ~30 Hz – 16 kHz
• Signal-to-Noise Ratio: ~58 dB with Dolby B
• Wow & Flutter:
• WRMS: ±0.075%
• Peak: ±0.16%
• Total Harmonic Distortion: ~1%

⸻

🎛 Features & Controls
• Logic-Controlled Mechanism: Smooth feather-touch buttons
• Tape Selector: Manual switch for Normal / CrO₂ / Metal
• LED Peak Level Meters: 6-segment LED indicators per channel
• Automatic Input Selector: Switches between mic and line input automatically
• Headphone Jack: 6.3mm front panel
• Mic Inputs: 2 front-panel mic jacks (6.3mm)

⸻

🔌 Inputs & Outputs
• Line Input: 80 mV
• Line Output: ~0.3–0.5 V
• Microphone Input: 0.2–0.4 mV
• Headphones: 6.3mm stereo jack (front)

⸻

📐 Dimensions & Power
• Dimensions (W × H × D): 435 × 115 × 240 mm
• Weight: Approx. 3.5 kg
• Power Consumption: Around 10–22 W
• Voltage: Usually 100V or 120V AC (depending on region)
• Manufactured in: Japan
• Production Era: Around 1983–1984

⸻

🛠 Maintenance & Notes
• Uses narrow belts that may need replacement after decades of use
• Oil-dampened cassette door (opens slowly and smoothly)
• Service manual is available online (~150 MB PDF)
• Pinch roller and belts are the most common wear parts
• Easy to use and repair for vintage gear lovers

⸻

💬 User Impressions

Pros:
• Reliable playback
• Supports Metal tapes
• Quiet and responsive controls
• Solid for its class

Cons:
• Lightweight build
• Flimsy mechanism if abused
• Narrow belts prone to wear
• No Dolby C or HX Pro
