Heco P7302 actieve speakers

Te koop set Heco actieve speakers uit 1973, toen onbetaalbaar 1500 gulden de set.

Gebruikssporen. In elke box zitten 3 versterkers voor laag, hoog en mid, volume is deels te regelen op het front.

Bieden vanaf 275 euro

• Manufacturer: Heco
• Model: P 7302 SLV
• Type: Active loudspeaker
• Years of manufacture: 1973 - 1979
• Made in: Germany
• Color: white RAL 9002, graphite black RAL 9011 (each with frame and aluminum grille in silver RAL 9006), from 1976 also natural walnut with black frame and grille
• Dimensions: 360 x 650 x 270 mm (WxHxD)
• Weight: 32 kg
• New price approx.: 1'400 DM on sale, 804 DM / piece (1.9.73: net)

Connections

• Number of inputs:
• 2x DIN (> 10W and <10 W).
• standard level inputs at 0.8V (1973 specification: 1.55V) at 5 kOhm latching; adjustable from 0.4 V to 3V

Technical Data

• Construction: 3-way closed, floorstanding speaker, active speaker.
• Chassis:
• Woofer: 2 x 205 mm

Midrange: 1 x 50 mm dome tweeter Tweeter: 1 x 25 mm dome tweeter Power amplifiers (continuous/dynamic): 55/70 W, 15/70 W, 8/70 W 3 power amplifiers

• Frequency response: 20 - 25,000 Hz
• Transitional ranges:
• Low frequency: 20 - 400 Hz

Midrange: 400 - 3,500 Hz

• High frequency: 3,500 - 25,000 Hz
