ONKYO HIGH END VINTAGE STEREOSET 1989

ONKYO A-8200 Amplifier
ONKYO T-4300 Tuner
ONKYO DX-2700 CD-player
ONKYO TA-2200 Tape deck

Good sounding and as good as new ONKYO A-8200 Infrared Wireless Remote Controlled Stereo 2x60W Amplifier, ONKYO DX-2700 High End Compact Disk Player, ONKYO T-4300 Quartz Synthesized AM/FM Stereo Tuner and ONKYO TA-2200 Stereo Cassette Tape Deck.

Absolute High Quality amp with enough power for an average room. Connection for turntable with MM or MC cartridge, as we have come to expect from ONKYO. 4 speakers on A, B or A+B circuit can be connected. Speaker connections are suitable for banana plugs.

Entirely in its original condition including original manuals. Will be delivered with remote control units on both Amp & CD

Fully functioning. Tuner has a proper reception; including antenna's.
Chic appearance in deep matte black paint scheme with large buttons.

Specifications ONKYO A-8200 Stereo Amplifier

Output Power:
60 W per channel at 8Ω (RMS, THD 0,06%; 20Hz - 20kHz)
100 W per channel at 4Ω, (DIN, 1kHz)
70 W per channel at 8Ω, (DIN, 1kHz)
Total Harmonic Distortion: 0,06% (at rated power)
IM Distortion: 0,06% (at rated power)
Damping Factor: 40 at 8 Ω
Frequency Response: 15 Hz - 30 kHz, ±1 dB
Signal-to-Noise Ratio (IHF A ):
Phono MM : 80 dB (5 mV input)
Phono MC : 70 dB (0,5 mV input)
Source Direct (CD) : 102 dB
Input Sensitivity/Impedance:
Phono MM : 2,5 mV/50 kΩ
Phono MC : 350 µV/220 Ω
Tuner, Cd, Aux, Video : 150 mV/50 kΩ
Tape Play : 150 mV/50 kΩ
Phono MM Overload: 150 mV (1kHz, THD 0,06%)
Output Sensitivity/Impedance:
Tape Rec : 150 mV/3 kΩ (phono)
Selective Tone Control: ±15 dB at 50 Hz; ±6 dB at 10 kHz
Bass Control : ±10 dB at 100 Hz
Treble Control : ±10 dB at 10 kHz
Power Requirements: 120/220/240 V, 50/60 Hz
Dimensions (W x H x D): 435 x 143 x 287 mm (17-1/8" x 5-5/8" x 11-5/16")
Weight: 7,2 kg (15,9 lbs)

Specifications ONKYO DX-2700 Compact Disk Player

Disc format: CD
Digital converter: AD1860N-J, 18-bit, 8 x oversampling
CD Mechanism: KSS-150A
Frequency response: 2Hz to 20kHz
Dynamic range: 98dB
Signal to Noise Ratio: 106dB
Channel separation: 100dB
Total harmonic distortion: 0.003%
Line output: 2V
Dimensions: 435 x 118 x 312mm
Weight: 5.1kg
Finish: black

Specifications ONKYO T-4300 Stereo AM/FM Tuner

Type: Mono/Stereo Tuner
Tuning Bands: FM, MW
Tuning Scale: Digital
FM Tuning Range: 87.5 to 108.0 MHz
MW Tuning Range: 522 to 1611 kHz
Sensitivity: 0.9uV (FM), 25uV (MW)
Signal to Noise Ratio: 66dB (FM), 40dB (MW)
Distortion: 0.2% (FM), 0.8% (MW)
Frequency response: 30Hz to 15kHz (FM)
Output: 750mV (FM), 150mV (MW)
Dimensions: 435 x 72 x 265mm
Weight: 2.6kg

Specifications ONKYO TA-2200 Stereo Cassette Tape Deck

Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: 1 x DC servo, 1 x DC
Tape Type: type I, CrO2, Metal
Noise Reduction: B, C
Headroom Extension: HX Pro
Frequency Response: 20Hz to 19kHz (Metal tape)
Signal to Noise Ratio: 78dB (dolby C)
Wow and Flutter: 0.07%
Input: 60mV (line)
Output: 0.5V (line)
Dimensions: 435 x 122 x 262mm
Weight: 4.4kg
Accessories: RC-146T remote control
Year: 1989
