Maxpeedingrods 24 Ways Adjustable Damper Coilovers compat...

Maxpeedingrods 24 Ways Adjustable Damper Coilovers compatible for Honda Prelude 1992-2000

Introduction

MaXpeedingRods T6 (also known as SP1) lowering coilover, standard with adjustable rebound damping, separate height adjustment without changing preload, developed damping oil and upgraded racing springs, adjustable camber plate(for some vehicles) and decent outlook , offers you more ability to tune your suspension on performance and gives your vehicle more impressive appearance. Besides, all our coilover are assembled in dust-free factory, which turns out good quality and long life.

Application

Compatible For HONDA PRELUDE BB1-BB9 1992-2001

Note:

This coil-over is perfectly suitable with TYPE S, SiR, and S SPEC which has strut tower bar mounting points.

It can also be used directly for some USDM Preludes which have reserved factory mounting points.

For some models without mounting points, you can remove the 2 additional studs.




Specification

Top mounts: pillow ball top mounts

Damping: 24 levels rebound damping adjustable

Spring rate Front: 8 kg/mm (448 lbs/in)

Spring rate Rear: 7 kg/mm (392 lbs/in)

Spring length Front: 180mm

Spring length Rear: 200mm

Adjustable height: lowering 1-3 inch

Coilover overall length Front: 420mm-465mm

Coilover overall length Rear: 550mm-645mm

Shock type: Twin tube

Spring preload: 7-10 mm

Color: black bodly with blue spring

Package included:

complete coilovers for 2 front and 2 rear

a pair wrench for height adjustment

Dimension

weight: 25000g

size: 63*50*20cm

Feature

1. Lowered height adjustment from 1" - 3" which allow lower center of gravity and also add a more aggressive stance.

2. A 24 rebound damping adjustment level allows you the ability to perfectly dial in your coilover setup. You will experience better ride quality in all road conditions.

3. Pillow ball top mounts improve the steering feel and response.

4. Full length dust boot keeps shaft and oil seal from damage.

5. Upgraded damper adjust knob makes damping setting easier.

6. Upgraded valving for more smooth ride.

7. Twin-Tube structure allows sufficient stroke within the shock absorber.

8. High-Performance Damping Oil--maintains a stable viscosity in a broad temperature range, which sustains smooth stroke and reliable damping force in a variety of circumstances.

9. High Tensile performance spring - STRESS TESTED OVER 600,000 times while the spring distortion is less than 0.04%.

10. Decent appearance benefits from CNC machined parts and special surface treatment.

11. Most pieces in our coilover systems, including mounts, collars and spring perches, are made from 6061-T6 Billet Aluminum resulting in light weight, durable and rust resistant components.

12. Complete Suspension Kit of 4 Shock Absorbers & 4 Springs for an easy installation.

13. Separate height adjustment does not affect damper stroke and height can be adjusted with coilovers installed on the vehicle.

14. All coilovers were produced and assembled at dust-free factory which guaranteed the highest quality.
Warranty: one year warranty for any manufacturing defect
