Processor
6-Core
3.2GHz 6-core Intel Core i7
Turbo Boost up to 4.6GHz
12MB shared L3 cache

Memory
32GB of 2666MHz DDR4 SO-DIMM memory

PCIe-based SSD 1TB

Graphics
Intel UHD Graphics 630

Video Support
Support for the following combination of maximum concurrent display setups:
Up to three displays:
Two displays with 4096-by-2304 resolution at 60Hz connected via Thunderbolt 3 plus one display with 4096-by-2160 resolution at 60Hz connected via HDMI 2.0
Up to two displays:
One display with 5120-by-2880 resolution at 60Hz connected via Thunderbolt 3 plus one display with 4096-by-2160 resolution at 60Hz connected via HDMI 2.0
Thunderbolt 3 digital video output supports
Native DisplayPort output over USB-C
Thunderbolt 2, DVI, and VGA output supported using adapters (sold separately)
HDMI 2.0 display video output
Support for one display with 4096-by-2160 resolution at 60Hz
DVI output using HDMI to DVI Adapter (sold separately)
Audio
Built-in speaker
3.5 mm headphone jack
HDMI 2.0 port supports multichannel audio output
Connections and Expansion
Four Thunderbolt 3 (USB-C) ports with support for:
DisplayPort
Thunderbolt 3 (up to 40 Gb/s)
USB 3.1 Gen 2 (up to 10 Gb/s)
Thunderbolt 2, HDMI, DVI, and VGA supported using adapters (sold separately)
Two USB-A ports (up to 5Gb/s)
HDMI 2.0 port
Gigabit Ethernet port (configurable to 10Gb Ethernet)
3.5 mm headphone jack
Communications
Wi-Fi
802.11ac Wi-Fi wireless networking
IEEE 802.11a/b/g/n compatible
Bluetooth
Bluetooth 5.0 wireless technology
Ethernet
10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)
Configurable to 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb, and 10Gb Ethernet using RJ-45 connector)
Size
Height: 1.4 inches (3.6 cm)
Width: 7.7 inches (19.7 cm)
Depth: 7.7 inches (19.7 cm)
Weight2
2.9 pounds (1.3 kg)
Electrical and Operating Requirements
Line voltage: 100–240V AC
Frequency: 50Hz to 60Hz, single phase
Maximum continuous power: 150W
Operating temperature: 50° to 95° F (10° to 35° C)
Storage temperature: –40° to 116° F (–40° to 47° C)
Relative humidity: 5% to 90% noncondensing
Operating altitude: tested up to 16,400 feet (5000 meters)
Typical acoustical performance: Sound pressure level (operator position): 5 dBA at idle3
In the Box
Mac mini
Power cord
Operating System
macOS
