Areca ARC-1280ML SAS raid/hba

2x Areca ARC-1280ML SAS raid/hba

ARC-1280MI
(12-port PCIe to SATA ll RAID Adapter)

Areca high-performance PCI-Express bus to SATA RAID host adapters support 12SATA ll peripheral devices on a single host adapter. SATA RAID controller has the same RAID kernel of its field-proven external RAID controllers. Applications that benefit most features from these controllers including NAS, server RAID solutions, web server, supercomputing, near-line backup, security systems and streaming and streaming applications server.
Adapter Architecture



Intel 800MHz IOP341 I/O processor
PCI-Express X8 bus
One DIMM socket with default 256MB of DDR2-533 SDRAM with ECC protection, Upgrade to 2GB. An ECC or non-ECC SDRAM module using X8 or X16 chip organization
Write-through or write-back cache support
Support up to 12/16/24 SATA II drives
Multi-adapter support for large storage requirements
BIOS boot support for greater fault tolerance
BIOS PnP (plug and play) and BBS (BIOS boot specification) support
Intel RAID 6 Engine to support extreme performance RAID 6
NVRAM for RAID event & transaction log
Redundant flash image for adapter availability
Battery Backup Module (BBM) ready
ARC-6120BA-T112
RoHS Compliant

RAID Features
RAID level 0, 1, 1E, 3, 5, 6 (if RAID 6 engine supported) and JBOD
Multiple RAID selection
Array roaming
Online RAID level/stripe size migration
Online RAID capacity expansion and RAID level migration simultaneously
Online Volume set growth
Instant availability and background initialization
Automatic drive insertion/removal detection and rebuild

Greater than 2TB per volume set
Support S.M.A.R.T, NCQ and OOB Staggered Spin-up capable drives
Support spin down drives when not in use to extend service life (MAID)
Support NTP protocol to synchronize RAID controller clock over on-board Ethernet port

Monitors/Indicators

System status indication through HDD activity/fault connector, LCD Connector and alarm buzzer

SMTP support email notification
SNMP support for remote notification
I2C Enclosure management ready
Server chassis features the 36-ckt Mini-SAS connector (SFF-8087) on its SAS backplanes

RAID Management
Field-upgradeable firmware in flash ROM
In-Band Manager
Hot key boot-up McBIOS RAID manager via BIOS
API library for customer to write its monitor utility
Support Command Line Interface (CLI)
Browser-based management utility via ArcHttp Proxy Server
Single Admin Portal (SAP) monitor utility
Out-of-Band Manager
Firmware-embedded Browser-based RAID manager, SMTP manager, SNMP agent and Telnet function via on-controller Ethernet port
API library for customer to write its monitor utility
Push Button and LCD display panel

Software Drivers
Windows 7/2008/Vista/Server 2003/XP/2000
Linux (RedHat, SuSE, Debian, Mandrake, TurboLinux, CentOS, etc.)
FreeBSD
Novell Netware 6.5
Solaris 10 x86/x86_64
SCO UnixWare 7.x.x
Mac OS 10.4.x/10.5.x/10.6.x (EFI BIOS support)

Environmental/Physical
Mechanical

Dimension: ARC-1231ML/1261ML/1280ML: 98.4(H) x 237.5(L) mm
ARC-1280: 98.4(H) x 237(L) mm

Environmental Specifications

Operating: Temperature:+5°c to +50°c
Humidity: 15-80%
non-condensing

Storage Temperature: Temperature:-40°c to 70°c
Humidity: 5-90%
non-condensing

Electrical

Power Requirements: 4.95W max.On3.3V
6.22W max.On+12V
