2x Tyan S5510 moederboard

2x Server/workstation moederboard met onboard managment IPMI.

Processor
Supported CPU: Series Intel Xeon E3-1200, i3-2100 (32nm / 22nm) series Processors
Socket Type / Q'ty: LGA 1155/ (1)
Thermal DesignPower (TDP) wattage: Max up to 95W
Chipset PCH: Intel C204
Chipset Super I/O: Nuvoton 5577D

Memory
Memory: Supported DIMM Qty: (4) DIMM slots
DIMM Type / Speed: Unbuffered ECC DDR3 1600/1333/1066/800
Capacity: Up to 32GB
Memory channel: 2 Channels
Memory voltage: 1.5V

Expansion Slots
PCI-E: (1) PCI-E Gen.2 x4 slot / (2) PCI-E Gen.3 x8 slot (w/x8 link) / (1) PCI-E Gen.2/Gen.3 x4 slot
Note: use Intel Ivy Bridge CPU to support PCI-E Gen.3

LAN
Port Q'ty: (3) GbE ports
Controller Intel 82574L

Storage
Connector: (6) SATA
Controller: Intel C204
Speed: (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black color)
RAID: RAID 0/1/10/5 (Intel RST)

Graphic
Connector type: D-Sub 15-pin
Resolution: Up to 1600x1200@60Hz
Chipset: Aspeed AST2150

TPM
Chipset: Infineon SLB9635
Version: TPM v1.2

Input /Output
USB: (9) USB2.0 ports (4 at rear, 4 via cable, 1 type A onboard)
COM: (2) ports (1 at rear, 1 via cable)
RJ-45: (3) GbE ports
Power: SSI/ATX 24-pin + 8-pin power connectors
Front Panel: (1) 2x12-pin SSI front panel header
SATA: (6) SATA-II connectors

System Monitoring
Chipset: Nuvoton 5577D
Voltage: Monitors voltage for CPU, memory, chipset & power supply
Fan: Total (5) 4-pin headers
Temperature: Monitors temperature for CPU & system environment
LED: Fan fail LED indicator / Over temperature warning indicator / Fan & PSU fail LED indicator
Others: Chassis intrusion detection / Watchdog timer support
Server Management
Onboard Chipset: Onboard Aspeed AST2150
AST2150 IPMI Feature: IPMI 2.0 compliant baseboard management controller (BMC) / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2150 iKVM Feature: 24-bit high quality video compression / Dual 10/100Mb/s MAC interfaces

BIOS
Brand / ROM size: 8MB / AMI
Feature: Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI 2.0 power management /Power on mode after power recovery / User-configurable H/W monitoring / Auto-configurable of hard disk types

Physical Dimension
Form Factor: Micro ATX
Board Dimension: 9.6"x9.6" (243.8x243.8mm)

Regulation
FCC (DoC): Class A
CE (DoC): Yes

OperatingEnvironment
Operating Temp.: 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp.: - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating: 90%, non-condensing at 35° C Humidity
RoHS RoHS 6/6 Compliant Yes


Bieden per stuk, twee beschikbaar.
