ANT lasbeschermer - Splice protector - glasvezelkabels

Te koop aangeboden tientallen doosjes ANT lasbeschermers ( 150stuks per doosje),ook wel splice protector genoemd van het merk Telent, deze worden gebruikt om gelaste glasvezelkabels te beschermen. De ANT lasbeschermer dient over het gelaste deel van de glasvezelkabel te worden geschoven en vervolgens wordt deze met de ANT lasbeschermer tool dicht geknepen. Op deze manier is het gelaste deel van de kabel beschermd. De lasbeschermer kan al enkele seconden na het lassen aangebracht worden.

Vraagprijs € 35,- per doosje

Specificaties
Merk Telent EAN 9503527941722 Kleur Zilver Lasbeschermer ANT Itemnaam Lasbeschermer, ANT, doosje 150st, Telent Artikelnummer M00001072 Soort product Lasbeschermers.



Glasvezel stripper- Glasvezel Lasapparaat - Inno view - lasmachine - cleaver - miller - spliceprotectors - PG13.5 wartels - LC(DX), SC(SX), ST (SX) of E2000 (DX) adapters - Glasvezel demper - LC (1 dB) - ignal fire glasvezel fiber optic machine - Duplex adapter, LC naar LC - glasvezel lazer tester - Powermeter glasvezel tot 1650 wave -

TELENT AN00 377 128-150 For installation, the fiber optic splice is placed in the middle of the splice protection and then closed in a defined manner with the splice protection press.
The unprotected splice is embedded in the permanently elastic compound and thus protected from environmental influences.
The splice protector can then be removed from the splice protection press immediately, without waiting time, and after insertion into the splice protection holder, it can be placed in a splice cassette, for example.

Specification:

• Simple, safe and fast assembly
• Universally applicable splice protection for all fibers up to 250µm
• Suitable for all splicing devices of different manufacturers
• Mountable without any external energy such as heat source or radiator
• No use of chemicals
• Can be used in all currently known LWL storage cassettes
• Corrosion resistance
• No attenuation increase

Material:

• Aluminium sheets and permanently plastic mass (PIB)
• Weight: 60g (150 pieces)
• splice protection fibre diameter: 250 + 20 µm
• Splice protection processing temperature range: -5°C ~ +45°C
• Splice protection operating temperature range: -20°C ~ +70°C
• Dimensions: 31 x 3 x 1 mm
