Standard Features
Dimensions: Height - 318 mm
Width - 305 mm
Depth - 330 mm
Weight - 9.5 kg
Printhead: 102 mm/812 dots
203dpi - 8.0 dots/mm or 300dpi - 11.8 dots/mm
Fonts Available: Standard, Reduced, Bold, OCR-A-Like, CG Triumvirate, CG Triumvirate Bold, EFF Swiss Bold
1x to 7x magnification, scalable fonts 4 to 250 pt
Downlodable fonts for japanese, chinese, arabic, etc...
PC/Host Interface:
IEEE 1284 parallel (Centronics mode)
USB (Universal Serial Bus)
Asynchronous RS-232C
NONE, XON/XOFF, DTR, and CTS Flow Control
2400, 4800, 9600, 19.2K, 38.4K, 57.6K or 115.2K baud
ASCII data transmisison code
Memory: 4MB flash, 16 MB SDRAM total: transmit, receive, image, format, internal, downloadable font
Character Sets Available:
Monarch Internal
ANSI
DOS Code Page 437
DOS Code Page 850
Black to White Print Ratio: 30% black maximum per square inch
