General
Depth 15.8 in
Height 13.1 in
Printer Type Label printer - direct thermal / thermal transfer - monochrome
Weight 33.1 lbs
Width 9.4 in
Environmental Parameters
Humidity Range Operating 25 - 85%
Max Operating Temperature 104 °F
Min Operating Temperature 41 °F
Expansion / Connectivity
Connections 1 x parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25) ¦ 1 x USB - 4 pin USB Type B ¦ 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45
Expansion Slot(s) Expansion slot
Flash Memory
Flash Memory 2 MB
Manufacturer Warranty
Service & Support 1 year warranty
Service & Support Details Limited warranty - 1 year
Media Handling
Max Media Size (Custom) 4.65 in
Max Printing Width 4.16 in
Media Feeder(s) 1 x manual load - 1 rolls - Roll (4.65 in)
Media Sizes Roll (4.65 in), Roll (4.5 in), Roll (1 in)
Media Type Labels, thermal paper
Networking
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet
Networking Network adapter - internal
Remote Management Protocol SNMP
Power
Frequency Required 50/60 Hz
Power Consumption Operational 155 Watt
Power Device Power supply - internal
Voltage Required AC 120/230 V
Printer
Barcodes EAN/JAN, Code 93, Industrial 2 of 5, Code 39, UCC/EAN-128, NW-7, QR code, MaxiCode, MicroPDF417, Code 128, UPC, Postnet , PDF417, MSI-Plessey, Data Matrix, ITF, Kix (Netherlands) Post, GS1 DataBar-14, RM4SCC
Built-in Devices Status LCD
Connectivity Technology Wired
Display Resolution 2 lines x 16 characters
Fonts Included 21 x bitmapped ¦ 4 x outline
Interface Parallel, USB, Ethernet 10/100Base-TX
Max Resolution ( B&W ) 203 dpi
Print Speed Up to 360 inch/min - B/W
Printer Features RFID ready
RAM
RAM Installed ( Max ) 4 MB
Technology / Form Factor SDRAM
