P1 Active Splitter Plus

P1 4 Port Active Splitter Plus makes from your P1 port 4 new galvanic isolated master ports.
P1 outputs respond the same as P1 port.
This Splitter is compatible with almost any charging station on every output.
All inputs working with a schmitt trigger

• Black ABS case 45x75x28 mm
• 1 RJ12 P1 black port in, with LED indication on P1 signal.
• 4x RJ12 grey galvanic separated P1 ports out, with LED indication on P1 signal.
• USB-C 5V DC for optional power supply.
• Can be used on all DSRM P1 meters.
• DSRM 2,3 en 4 with optional power supply (Min. 1A 5V DC).
• DSRM 5 as total power used more than 250mA then you need to use an external power supply (1A 5V).
• Self-consumption: ~50 mA with 5VDC.
• Working temperature -40 deg. to +85 deg.
• Supplied with 1m RJ12 cable.
• P1 Powered with Skotty Diode Max. 0.21V Forward Drop

Internally with 5V powered with Smart Diode max. 0.1V Forward Drop
Can be mounted on the wall with 1 or 2 screws.
Warranty 5 years
EAN: 6150619675619
