Bidirectional KNX radio switch actuator 1-fold, IP55, surfac

Bidirectional KNX radio switch actuator 1-fold, IP55, surface mounting, q-link TRE201 – Hager – 3250615989345: Funk KNX AP output 1f, IP55, 10A, q-link TRE201 bus system KNX, bus system KNX radio, bus system radio bus, other bus systems without, radio bidirectional, surface-mounted installation, width in modular units 0, on-site/manual operation, with LED display , number of binary inputs 0, max. switching capacity 2300W, output power 2300W, max. number of switching outputs 1, max. switching current 10A, rated current 10A, rated operating voltage 195... 253V, min. Radio AP output 1-fold IP55 10A, quick link. Radio KNX AP output device IP55 for switching loads in connection with quicklink radio products or KNX-capable bus systems via KNX radio. The device converts the switching information into bidirectional commands. Output ON/OFF functions, moving shutters and blinds, slat adjustment, time functions, priority, 8 freely definable scene functions. Range: approx. 30m inside, 100m outside Measurement of the ranges via TX100 possible. Amplifier function (repeater) adjustable via TX100.
