Dr. Scientist The Elements Ltd edition overdrive/distortion

Dr. Scientist The Elements Ltd edition overdrive/distortion

The Elements is a dual-channel overdrive/distortion with a wide gain range and a full 3 band equalizer. To increase its versatility, we’ve added toggle switch options for clipping modes, bass cut frequencies, and midrange frequencies. Whether you’re looking for high gain metal distortion or a clean equalizer, The Elements can fulfill a role on any pedalboard. Like all Dr. Scientist pedals, the Elements can be used with guitar, bass, synths, and many other instruments.

Features

• Low and High gain distortion channels selectable via toggle switch
• Active 3 Band EQ
• Symmetrical or Asymmetrical clipping diode options
• High quality analog signal path
• Premium parts and components throughout
• True Bypass with soft touch relay switching
• Full control over wet/dry mix
• Expression pedal control over Mix
• Top mounted audio and power jacks
• Designed and handmade in B.C., Canada

Knobs

• Gain – Increases the amount of distortion
• Volume – Controls the effect (Wet) signal level
• Mix – Adjusts the balance between the input signal (Dry) and the effect (Wet) signal
• Gain Toggle – Chooses between low- and high-gain channels
• Clip Toggle – Chooses between Symmetrical, Asymmetrical, or no clipping
• Bass Cut – Chooses between 3 levels of bass cut
• Mid Freq – Chooses between 3 centre frequencies for the Mid control
• Bass – Adjust the low frequencies
• Mid– Adjust the midrange frequencies
• Treble – Adjust the high frequencies
• Bypass – Engage or disengage the effect
