TH2821 automatischeportable R,L,C meter met accu

TH2821 Portable LCR Meter Handheld Bridge Lcr Meter 0.3% Accuracy+ 0.1%
Goed werkend.

It has measurement accuracy of 0.3% and 4-bin sorting. Applied complete 5-terminal measurement configuration solves problem of measurement for equivalent series resistance and capacitor with small dissipation that other portable LCR meters cant solve. It can replace general low-frequency LCR meter. With battery external power supply, the meter is ideal for field and portable applications, such as component inspection at fixed place, and immediate measurement
Features Product Model:
TH2821 LCR tester series LCR test parameter |Z|,R,C,L,D,Q Test frequency 100Hz,120Hz,1kHz,10kHz Test level range 0.3Vrms Basic accuracy 0.30% Test speed or time 3 times/s Equivalent circuit Serial and parallel Range mode Auto,hold Correction function Open/short sweep correction Comparator function 4 bins: NG / P1 / P2 / P3 Display range R, X, Z 0.1m 9.999 M C 0.01 pF 9999uF L 0.01 uH 9.999kH D 0.0001 9.999 Q 0.0001 9999 % -199.98 Displayer Large LCD display Display mode Direct read, , %
