Rooftop airco. Topmerk CIAT. Ongebruikt, bouwjaar 2025. Direct leverbaar. Inclusief alle originele accecoires

Kant en klaar gesloten koelsysteem. Geen koelmonteur nodig!
Koeling en ventilatie in een compact apparaat.

Voor vast opstelling op het dak of in te zetten als grote mobiele airco.
Eenvoudig aan te sluiten en direct inzetbaar!
Stroom aansluiten, luchtslangen bevestigen en koelen maar.

Merk: CIAT
Model: VECTIOS
Type: RPJ0120
Inclusief diverse opties, zie foto's.

Rooftop airco.
Degelijke industriële kwaliteit, geschikt voor 24/7 gebruik onder zware condities.
Energiezuinige EC ventilatormotoren met frequentie regelaar.
Electronische expansieventielen.
Detectie van luchtweerstand en automatische compensatie luchtdebiet.
Vervuiling van luchtfilter detectie en diverse beveiligingen.
Automatische"free cooling" optie, voor energiezuinige koeling met alleen ventilatie, indien de buitentemperatuur lager dan de ruimtetemperatuur is
Winterregeling.
Luchtvochtigheid sensoren en regeling

Monoblok, geen koeltechnische installatie vereist.
Gesloten koeltechnisch system.
Luchtbehandeling, airconditioning, automatische vrije koeling, luchtfiltratie.

Ook ideaal voor sportscholen.
Ventilatie en koeling in een apparaat.

Koelvermogen: 30,4 kW
Aansluitspanning: 380 /400 V - 3 fase
Geschikt voor buitenopstelling.

Nieuw in verpakking, verkeer besteld.
Zit nog in de fabrieksgarantie.
Origineel in gesealde verpakking.

Use
The unit is connected directly to an air distribution ductwork without additional elements or equipment, pipes, cables, etc. taking up no floor space at all. This design reduces the cost of installation, facilities connections and ensures reliable operation.
The range of capacities of these units allows for the air conditioning of medium and large surface areas used for business or industry.
A vast number of options meet many operating requirements, such as:

• Recovery of the extracted air energy.
• Free-cooling.
• Air renewal.
• Indoor air quality control.
• Air filtration.
• Auxiliary devices for heating.
• Extension of operating limits for adaptation to extreme temperatures.

These units are equipped with electronic axial fans in the outdoor circuit, electronic plug-fans in the indoor circuit, air coils, hermetic scroll compressors and electronic control with microprocessor, optimized components for the refrigerant. All of the units are tested and checked in the factory.
Description

• Ecodesign compliant Lot 21 Tier 2 (2021)
• Hermetic scroll-type compressors in tandem design
• Plug-fans (free-wheel) with EC motors
• Electronic Expansion Valves
• Lightweight box for convenient installation
• Folding hood cover for transport
• Double wall insulated panels
• Dual locking system of a high quality
• Multiple recovery options on the extracted air energy
• Removable condensates drain pan
• On-site easily convertible airflow (supply and return)
• Electronic axial fans for low noise level
• Adaptation roofcurbs for replacing units on site

HIGH ENERGY EFFICIENCY AND ENVIRONMENTAL RESPONSIBILITY

• Exceeds requirements on seasonal efficiency from Ecodesign regulation EU 2016/2281
• Active Recovery and Passive Recovery options on the exhaust air energy
• R-410A non-depleting refrigerant
• Elimination of wooden pallets for handling

PACKAGED SYSTEM FLEXIBILITY

• Single-packaged system
• Reduces costs of transportation, installation and maintenance
• Reduces size and weight for stacked in truck or container transportation and conveninent helicopter or crane lift
• Assemblies conceived for new projects as well as for renovation works
• Standard and adaptation roof-curbs are available for a number of existing models from different manufacturers
• All the components to manage the airstream (supply, return or fresh air) are integrated in the unit
• The unit ships fully programmed and set-up from the factory
• Wide set of configurations and options for optimal adaptation to the installation requirements

FULL RELIABILITY

• Robust design and manufacturing process
• High quality components
• Performance certified by Eurovent

EXTENSIVE SCOPE

• More applications with new options beyond comfort for fresh air, food retail, domestic hot water, dehumidification…
• Wider outside air temperature range, from -15ºC up to 52ºC (cooling-only unit)
• Outdoors ambient conditions: corrosion protection, humidity
• Indoor Air Quality, IAQ: with a number of filtration options with fouling detection and CO2 sensors

ADVANCED CONTROL VECTIC

• Single control for the whole range
• Dedicated to enhanced operation at part load conditions for increasing the seasonal efficiencies
• Manages staged multi-scroll compressors and EC plug-fans
• Improved all-seasons operation and defrosting strategies
• Manages new options for the range
• Multiple protocols available for BMS integration
• Many options for remote management platforms

Wij hebben veel airco's, warmtepompen, industriële koeling en luchtbehandeling.
Bekijk ook onze andere advertenties.

Neem contact met ons op voor beschikbaarheid of vrijblijvend deskundig advies: 030-6570123

Prijs exclusief 21% btw, wordt altijd geleverd met factuur.

Af te halen in Helmond op afspraak of verzending per pallet tegen meerprijs.
