Marantz PM17

Goed werkende Marants PM17 versterker.

Behuizing netjes, bovenop enke vegen. Afstandbediening: sommige bedrukking lettertjes iets wat vervaagd door het gebruik.



Years of manufacture: 1997-1999
Color: Champagne
Type: Analog
Remote control: yes
Dimensions in mm: 458 x 110 x 444 (W x H x D)
Power consumption: 180 W at full load, 47 W idle. 0 W off.
Weight: 15 kg

Connections:
Number of inputs: 6
6x Line (150 mV/10 kO)
1x MM (2.5 mV/47 O)
1x MC (200 myV/100 O)
Number of outputs: 2
1x PreOut (/)
1x loudspeaker

Technical Data:
Continuous power (at harmonic distortion) 0,01%
8 Ohm: 60 Watt 4 Ohm: 100 Watt (120 W - Stereoplay 9/1997, p.48)

Sine power
8 Ohm: 2x 86 W (data according to Stereo 1/1998, p.53)
4 Ohm: 2x 154 W (data according to Stereo 1/1998, p.53) 2 Ohm: 2x 166 W (data according to Stereo 1/1998, p.53)

impulse power (into 4 Ohm): 2x 164 W
Total harmonic distortion: 0.01 %.

Distortion factor at full power/ -1dB: 60 dB
Bass: +- 8dB Treble: +- 8dB

Loudness: No
Mute: Speaker off
Direct/Line-Straight: yes

Special Features:
per high level channel 2 HDAM- modules (High Dynamic Amplification Module = voltage boosters packed in copper caskets),
toroidal transformer,
Output sockets for pre-amplifier (Pre-Amp).
Switchable phono input for both MM and MC systems. Temperature display on the front panel Remote Control RC-17PM, Marantz Remote Control System: Remote control can also control CD player, tuner and Marantz tape.

Unit largely made of metal, even the controls
