Bewerkingscentrum Hyuandai Wia F500 Plus

CNC controller: FANUC
XYZ =1.060x510x635
Distance spindle nose – table surface mm: 150 – 785
Table dimensions mm: 1.200×500
Max. workpiece weight kg: 800
Spindle speed rpm: 10.000
Spindle drive power kW: 15/11
Spindle torque Nm: 286/143
Tool magazine slots: 30
Max. Tool Diameter
With free neighboring places mm: 150
With occupied neighboring places mm: 90
Max. Tool Length mm: 300
Max tool weight kg: 8
Tool-to-tool time s: 4
Chip-to-chip time s: 8
Equipment
Chip conveyor
Transformer
Electronic handwheel
Rated power kVA: 30
Basic machine dimensions / weight
Length mm: 4.063
Width mm: 2.670
Height mm: 3.096
Weight kg: 7.500

Spannmittel nicht einbegriffen/fixtures not included
